LONGi Hi-MO X6 Guardian LR5-72HTHF 570W

Discover the LONGi Hi-MO X6 Guardian LR5-72HTHF 570W solar panel with high efficiency and up to 600W power output.

  • Maximum Power (Pmax): 570W
  • Open Circuit Voltage (Voc): 48.60V
315 AEDincl. VAT
Full Specifications

Features

Equipped with HPBC cell, inheriting

Equipped with HPBC cell, inheriting high-efficiency gene

Unique frame design effectively reduces

Unique frame design effectively reduces the impact of dust accumulation

High reliability, stable operation under

High reliability, stable operation under harsh conditions

Suitable for industrial and commercial

Suitable for industrial and commercial color steel tile roofs and small angle installation scenarios

Overview

The LONGi Hi-MO X6 Guardian LR5-72HTHF 570W solar panel is designed to deliver exceptional performance with a maximum power output of 570W. Its advanced technology ensures high efficiency and reliability, making it an ideal choice for diverse solar applications.

Full specifications

Electrical

Maximum Power (Pmax)570W
Open Circuit Voltage (Voc)48.60V
Short Circuit Current (Isc)13.81A
Maximum Power Voltage (Vmpp)39.79V
Maximum Power Current (Impp)10.61A
Module Efficiency22.0%

Mechanical

Dimensions (L×W×H)2281×1134×30mm
Weight27.2kg
Frame MaterialAnodized aluminum alloy frame
GlassSingle glass, 3.2mm coated tempered glass

Environmental

Temperature Coefficient of Isc+0.050%/°C
Temperature Coefficient of Voc-0.230%/°C
Temperature Coefficient of Pmax-0.290%/°C
Front Side Maximum Static Loading5400Pa
Rear Side Maximum Static Loading2400Pa
Hailstone Test25mm Hailstone at the speed of 23m/s
Operational Temperature-40°C to +85°C
Maximum System VoltageDC1500V (IEC)
Maximum Series Fuse Rating25A
Nominal Operating Cell Temperature45±2°C

Certifications

  • IEC 61215
  • IEC 61730
  • ISO9001:2015
  • ISO14001:2015
  • ISO45001:2018
  • IEC62941
